• Version: Advantages over conventional systems:
  • NEW INNOVATION variable stroke: short stroke system, lubrication point can be overridden with small strokes
  • Higher pressure up to max. 400 bar
  • Larger output per stroke
  • Cartridge emptied in 222 strokes
  • Complete emptying thanks to special piston shape
  • Filling level of cartridge can be checked at any time
  • For 500 g cartridge
  • With high-pressure reinforced rubber hose
  • With seal and precision mouthpiece
  Technical information:
  • Pressure-side connection: M 10 x 1
  • Diameter grease pump piston: 10 mm
  • System burst pressure: 850 bar
  • Grease gun head burst pressure: 1200 bar
  • Dimensions LxWxH: 350 x 195 x 30 mm
  • Weight: 1,17 kg
  Special features:
  • The device can process greases up to NLGI 2 at 20°C
  • 97% effective supply volume
  • Easy assembly via vacuum principle
  • Pump piston, cylinder and O-ring with 6 μ fit accuracy (no grease l
• Weight: 1.17 kg
