• Version: • Grease gun connection pressure side via metal adaptor: M10 x 1
  • Filling nipple and vent valve: M10 x 1
  • Filling volume (cm³): 500
  • Filling options: 400 g grease cartridge, DIN 1284, grease filling equipment or bulk grease
  • Diameter of grease pump piston (mm): 9
  • Operation of grease pump piston: via hand lever
  • Delivery volume/stroke (cm³): proportional to hand lever travel, max. 1,4
  • Delivery pressure (bar): up to 400
  • System burst pressure (bar): 850
  • Grease gun head burst pressure (bar): 1200
  • Push rod operation: via T-grip
  • Cover: fixed
  • Grease gun tube wall thickness (mm): 1
  Specifications
  • With 1 reinforced hose, M 10 x 1, 11 x 300 mm
  • With 1 precision mouthpiece, 4 BA, M10 x 1
• Weight: 1.49 kg
