• ANSI no.: 80 H-1
• Pitch p (imperial): 1"
• Pitch p (mm): 25,4
• Clearance width b1 (mm): 15,75
• Roller Ø d1 (mm): 15,88
• Bolt Ø d2 max. (mm): 7,92
• Strap thickness si (mm): 4
• Fishplate height g (mm): 23,5
• Length of pin (mm): a1 max.: 35,9
• Breaking load DIN/ISO min. (N): 55600
• Inner link width b2 max. (mm): 24,3
• Max. width connecting link a1 (mm): 41
• Pin Ø d2 max. (mm): 7,92
• Pitch x inner width p x b1 (imperial): 1 x 5/8
• Pitch x inner width p x b1: 25,40 x 15,75
• Roll length (m): 5
• Roller Ø d1 max. (mm): 15,88
• Weight: 3 kg
