• ANSI no.: 100-1
• Pitch p (imperial): 1 1/4"
• Pitch p (mm): 31,75
• Clearance width b1 (mm): 18,9
• Roller Ø d1 (mm): 19,05
• Bolt Ø d2 max. (mm): 9,53
• Inner link width b2 max. (mm): 27,400
• Fishplate height g (mm): 29,2
• Length of pin (mm): a1 max.: 39,4
• Breaking load DIN/ISO min. (N): 87000
• ISO no.: 20 A-1
• Max. width connecting link a1 (mm): 44,9
• Pin Ø d2 max. (mm): 9,53
• Pitch x inner width p x b1 (imperial): 1 1/4 x 3/4
• Pitch x inner width p x b1: 31,75 x 18,9
• Pitch x inner width p x b1 min. (mm): 31,75 x 18,9
• Roll length (m): 5
• Roller Ø d1 max. (mm): 19,05
• Weight: 4 kg
