• ANSI no.: 60-1
• Pitch p (imperial): 3/4"
• Pitch p (mm): 19,05
• Clearance width b1 (mm): 12,57
• Roller Ø d1 (mm): 11,91
• Bolt Ø d2 max. (mm): 5,94
• Inner link width b2 max. (mm): 17,700
• Fishplate height g (mm): 17,7
• Length of pin (mm): a1 max.: 25,7
• Breaking load DIN/ISO min. (N): 31300
• ISO no.: 12 A-1
• Max. width connecting link a1 (mm): 28,6
• Pin Ø d2 max. (mm): 5,94
• Pitch x inner width p x b1 (imperial): 3/4" x 1/2"
• Pitch x inner width p x b1: 19,05 x 12,57
• Pitch x inner width p x b1 min. (mm): 19,05 x 12,57
• Roll length (m): 5
• Roller Ø d1 max. (mm): 11,91
• Weight: 7.96 kg
