• ISO no.: 24 A-1
• Pitch x inner width p x b1 (imperial): 1 1/2 x 1
• Pitch x inner width p x b1 (mm): 38,10 x 25,55
• Roller Ø d1 max. (mm): 22,23
• Pin Ø d2 max. (mm): 11,1
• Inner fishplate thickness Si (mm): 4,8
• Max. width connecting link a1 (mm): 50,3
• Breaking load DIN/ISO min. (N): 127000
• Pitch x inner width p x b1: 38,10 x 25,22
• Weight: 22 kg
