• ISO no.: 16 A-1
• Pitch x inner width p x b1 (imperial): 1 x 5/8
• Pitch x inner width p x b1 (mm): 25,4 x 15,75
• Roller Ø d1 max. (mm): 15,88
• Pin Ø d2 max. (mm): 7,92
• Inner fishplate thickness Si (mm): 3,25
• Max. width connecting link a1 (mm): 32,7
• Breaking load DIN/ISO min. (N): 56700
• Pitch x inner width p x b1: 25,4 x 15,75
• Pitch x inner width p x b1 min. (mm): 25,40 x 15,75
• Weight: 13.3 kg

Page 327
